XD-350C-LF (presumed to be lead-free wave soldering model of Xindong Technology)
Lead-free welding process (compatible with Sn/Ag/Cu, Sn/Cu and other lead-free solder)
Three-phase AC380V, 50Hz (industry standard)
Total power: Approx. 25-36kW (reference 25kW of similar models GSD-WD350CE and 36kW of TB980C)
Length approx. 4-4.5 m (e.g. GSD-WD350CE 4470mm, HRD-350 4120mm)
Maximum width: 350mm (model suffix "350C" usually corresponds to the maximum plate width of 350mm)
Adjustable range: 50-350mm (industry general design)
0.5-2m/min (refer to XD-250ML-LF transmission speed range)
Double hook and claw titanium alloy chain (deformation resistance, corrosion resistance)
Imported motor drive (e.g. Panasonic or SMC cylinder)
Three-stage independent temperature control (industry mainstream configuration, such as GSD-WD350CE three-stage preheating)
Room temperature ~250℃ (PID closed-loop control to meet the high temperature demand of lead-free)
Hot air circulation or infrared heating (modular design optional)
400-500kg (refer to 500kg of GSD-WD350CE and 430kg of TB980C)
Double wave crest (turbulence + advection wave), height 0-16mm adjustable
±1-2℃ (external PID heating, rapid heating and anti-riot tin)
Titanium alloy furnace (corrosion resistant, suitable for lead-free solder)
Automatic dregs design (reduce manual cleaning frequency)
Industrial computer + touch screen (Windows system, support English/Chinese switching)
Temperature curve storage/call, fault self-diagnosis, automatic switch
Production counting and logging (optional external printing function)
Constant pressure flux spraying (Taiwan lacquertreasure nozzle, uniform atomization)
Automatic spray width adjustment (for different PCB sizes)
Forced air cooling (outlet temperature ≤10℃, rapid cooling to reduce thermal stress)
Overload protection, emergency stop button, liquid level alarm, etc
